6000 XLUX Automatic Barrier

  • Aluminium extruded cabinet corners
  • Removable access doors on 3 sides
  • 100% continuous duty cycle
  • Single-phase supply, 3 phase motor
  • Two-stage motor drive
  • Inverter driven
  • Adjustable acceleration and deceleration
  • No springs or counterweights required
  • Pre-wired loop detector base for single
  • Heavy-duty roller plunger limit switches
  • Channel safety and entry/exit control
  • Programmable control panel
  • c/w fault diagnostic on-screen display
  • Built-in 8.2n safety edge controller
  • Manual override in case of power failure
  • Comes complete with M12 anchor bolts
  • Heavy-duty pillar block bearings

XLUX ADDED BENEFITS

  • Coloured safety sensing edges
  • LED strip boom lights
  • Powerful turnbuckle drive
  • Colours available on request
  • Low maintenance
  • Ease of installation

Optional Extras

  • Pogo tip support
  • Magnetic lock
  • Lorry Height Stop/ No Entry signs
  • Articulated arm (low ceilings)
  • Folding bottom skirt up to 6M
  • Hi-bar skirt up to SM
  • Plain pole up to 7M

Flexible Colours

Red with white, and black with yellow colours are standard with a monitored safety edge. Custom cabinet colours are possible at extra cost. Includes complimentary LED lights.
